10.0911

Basic parameter:

- Material:ADC12 corrosion-resistant die-cast aluminum housing;

                8mm clear safety glass ;

                anti-aging waterproof silicone gasket;

                304/316 stainless steel cover ring and external fasten screws

                PP Plastic recessed box


 - Finishing:Stainless steel


 -Installation:Ambient temperature:-30℃~+45℃;

                     Single Color:1x 0.5m length 2-cores Ø7.0mm power supply cable;

                     DMX512 controllable:1x 0.5m length 6-cores Ø7.5mm cable;

                     Nickled plated brass waterproof cable gland

Product model maximum power Beam angle Color temperature / color control mode Luminous flux Figure No
10.0911.A1V12 1.8W 10°/25°/40°/60° 2700K-5700K ON/OFF 187Lm /
10.0911.A1V12 1.8W 10°/25°/40°/60° 2700K-5700K ON/OFF 187Lm
10.0911.D1V12 0.3W 120° 2700K-5700K ON/OFF 27Lm
10.0911.D3FV12 0.6W 120° RGB DMX512 10Lm
