10.0942

Basic parameter：

- Material: ADC12 corrosion-resistant die-cast aluminum housing ;

               6mm clear safety glass ;

               anti-aging waterproof silicone gasket;

               304/316 stainless steel external fasten screws.

               PP plastic recessed box

- Finishing: Double layers of DUPONT UV-resistant polyester powder coating

- Installation: Ambient temperature：-30℃～+45℃；

                    Single Color: 1x 0.5m length 2/3-cores Ø7.5mm power supply cable；

                    DMX512 controllable: 1x 0.5m length 2/3-cores Ø7.5mm power supply cable  & 2x 0.5m 4-cores Ø6.0mm data cables with waterproof connector.

                    Nickled plated brass waterproof cable gland
