20.3014

Basic parameter：

- Material: ADC12 corrosion-resistant die-cast aluminum housing

                 Anti-aging waterproof silicone gasket;

                 3mm clear safety glass

                 304 stainless steel external fasten screws;

- Finishing: Double layers of DUPONT UV-resistant polyester powder coating

- Installation: Ambient temperature: -30℃～+45℃;

                      Single color: 1x 0.4m length 3-cores Ø7.0mm power supply cable

                      DMX512 controllable: 1x 0.4m length 3-cores Ø7.0mm power supply cable;

                      2x0.4m lenght 4-cores Ø6.0mm data cables.

                      Nickled plated brass waterproof cable gland
