Basic parameter：

- Material: ADC12 corrosion-resistant die-cast aluminum housing;

                  8mm clear safety glass

                  anti-aging waterproof silicone gasket;

                  stainless steel external fasten screws.

                  PP plastic recessed box

- Finishing: Double layers of DUPONT UV-resistant polyester powder coating

- Installation: recessed mounted；

                    Ambient temperature: -30℃～+45℃；

                    Tiltable: 0~15°

                    Vertical Rotation angle: 0~350°

                    Single Color: 1x 0.8m length 3-cores Ø7.5mm power supply cable；

                    DMX512 controllable: 1x 0.8m length 3-cores Ø7.5mm power supply cable；

                    & 2x 0.8m length 4-cores Ø6.0mm data cables.

                     Nickled plated brass waterproof cable gland
