10.0910

Basic parameter:

Material:304 stainless steel housing & cover ring;
            5mm clear safety glass;
            anti-aging waterproof silicone gasket;
            304 stainless steel external fasten screws;
            304 stainless steel recessed box.
Finishing:Stainless steel
Installation:Ambient temperature: -30℃~ +50℃ ;
Single Color: 1x 0.5m length 2-cores Ø7.0mm power supply
cable;
DMX512 compatible: 1x 0.5m length 6-cores Ø7.5mm
cable;
Nickel plated brass waterproof cable gland


Product model maximum power Beam angle Color temperature / color control mode Luminous flux Figure No
10.0910.E3SV24 0.6W 120° RGBW DMX512 10.2lm /
10.0910.D3CV24 1W 120° 2200K-5700K DMX512 90lm /
10.0910.D3V24 1W 120° 2200K-5700K ON/OFF 90lm /
10.0910.A1V12 2W 15°/25°/40°/60° 2200K-5700K ON/OFF 212lm /
  • LED inground mounted luminaire CE.zip

    Document size:

  • 10.0910 chips CREE-3030.pdf

    Document size:

  • 10.0910.A1V24 2W 3000K 25°.IES

    Document size:

  • 10.0910.pdf

    Document size:
